8/10-Gang CFB Series Box for Rectangular Covers, 5.50" Minimum Depth of Pour, Corrosion Resistant Paint

By Hubbell Wiring Device-Kellems

Catalog ID: CFB10G55CR

By Hubbell Wiring Device-Kellems
Catalog ID:  CFB10G55CR
Concrete Floorboxes, Galvanized Stamped Steel Box, Recessed, 8/10-Gang CFB Series Box for Rectangular Covers, 5.50" Minimum Depth of Pour, Corrosion Resistant Paint
  • Corrosion-Resistant Painted Recessed 8/10-Gang Rectangular Cover Floorbox
  • For Use In Concrete Floors
  • 5.59" Minimum Depth of Pour
  • Box Includes Installation Cover & 1/2" Prepour Cap
  • Each Gang Includes (1) 6" Solid Conductor Grounding Pigtail
  • (2) 2-Gang Dual Service & 4-Gang Single Service NEMA Spaced Plates Available

PreGalvanized Stamped Steel Box; Concentric Knock-Outs; Corrosion Resistant

Add to List

More Options

Where to Buy

Product Details

General

Application For Use in Concrete Floors
Application - For Use On Concrete
Color Metallic/Green Epoxy Paint
Construction Fabricated
Cover Shape Rectangle
Cover Type Rectangle
EU RoHS Indicator Contact Manufacturer
Knockouts 6) 3/4"-1 1/2", 2) 1/2"-3/4", 4) 1/2" -1 1/4", 2)1"- 2"
Material Pre Galvanized Steel
Mounting Method Cast Into Concrete
Number of Gang(s) 10-Gang
Series Recessed - CFB Series
Size 10-Gang
Sub Brand Recessed Concrete Floor Boxes
Type 10-Gang Recessed Floor Box
UPC 783585447414

Dimensions

Dimensions 10.96 in x 12.09 in x 5.59 in
Height 5.59 in
Length 10.96 in
Width 12.09 in

Conductor Related

Cable Entry Through Cover

Certifications and Compliance

Industry Standard(s)
  • cULus
  • UL514

Resources and Downloads

Installation/Instruction Manual (IOM)

Videos

SystemOne Recessed Floor Boxes
