5" Deep Cone Reflector Trim for 5" housing (P851-ICAT)

By Progress Lighting

Collection Name:  5" Recessed Trim

Catalog ID: P8268-21

By Progress Lighting
$38.17 USD
Collection Name:  5" Recessed Trim
Catalog ID:  P8268-21
5” Deep Open Trim in a Clear Alzak finish in the 5" trim family for use in recessed downlighting. UL and CUL listed for damp locations. The trim uses friction springs to attach to the housing to provide a flush fit against the ceiling. Compatible for use in Progress P851-ICAT.
  • 5" Deep open trim with gasket
  • Satin White finish flange
  • Use a PAR30/R30 bulb, 50 watt max.
  • Trim is only compatible with P851-ICAT
  • Socket mounts to trim for optimum performance and consistent lamp position
  • No light leaks around trim flange
  • Damp Location Listed
  • Uses friction springs to attach to the housing

Product Variations

Add to List

Buy from a Partner

More Options

Where to Buy

Product Details


Aperture 5 in
Can be mounted up or down No
Category General Recessed
Color Gray
Color Generic Grey
Construction Material - Main Aluminum
Convertible fixture includes both mounts No
Dusk to Dawn No
Finish Name Clear Alzak
Finish Type Plated
Fixture Type Recessed Trim
Lamp Included No
Mount location recessed
Mounting for outlet box included No
New Products No
Photocell No
Power Source Hardwired
Power Source Required? Yes
Prewired Yes
Room Type
  • Bedroom
  • Closets
  • Garage
  • Hall & Foyer
  • Kitchen
  • Sitting Room
Trim Type Open
Type 5in Trim
UPC 785247234325
Warranty Length 1-year Limited Warranty


Diameter - Inside 4.625 in
Diameter - Outside 6.5625 in
Dimensions 6.5625 in x 6.5625 in x 4.75 in
Height 4.75 in
Length 6.5625 in
Weight 0.27 lb
Width 6.5625 in
Width Diameter Descriptor dia.

Electrical Ratings

Voltage Rating 120 V

Certifications and Compliance

Americans with Disabilities Act No
Certified Listed cULus
Certified Listed Location Damp Location Listed
DarkSky No
ENERGY STAR Certified No
Energy Efficient No
EnergyStar No
JA8 No
Other Heavy Metal Content Indicator No
Title 20 Yes
Title 22 No
Title 24 No


Carton Quantity 18
Pallet Quantity 180

Resource Links

Instruction Sheet Number 93091581
