Wall Boxes, Data Box, Gangable, 2- Gang, 4" Depth, 2" KOs

By Bryant

Catalog ID: HBL985

By Bryant
Catalog ID:  HBL985
Wall Boxes, Data Box, Gangable, 2- Gang, 4" Depth, 2" KOs
  • Ideal for delivering power, data and AV side-by-side
  • Accepts industry standard wallplates for consistent appearance
  • Allows for multiple options for AV in-wall solutions
  • Accepts HBL989 Low Voltage Divider

Gangable design allows for design installation and flexibility;4 inch depth accommodates large cables and required bend radii

Contact Us
Add to List

More Options

Where to Buy
Get a Quote

Product Details

General

Application Flush mount in wall
Application - For Use On Wall
Color
  • Natural
  • Métallique
Construction Material - Main Pre Galvanzied Steel
EU RoHS Indicator Contact Manufacturer
Knockouts Top KOs- (2) 1/2", (2) 1/2"-3/4" TKO. Bottom KOs- (1)1", 1-1/4", 1-1/2", and 2". Back KOs- (2) 1/2"-3/4" TKO
Material Pre Galvanized Steel
Mounting Method Integral Mounting Bracket
Series Gangable
Size 2-Gang
Type Boxes
UPC 783585459752

Certifications and Compliance

Certified Listed cULus Listed
Industry Standard(s) cULus Listed

Logistics

Carton Quantity 10
