00:07Adjustment instructions. Bh nine through bh 70 tool.

00:11Balancers using spool lock, spool engage, activate

00:17spool lock by pulling out slightly and rotating one quarter turn in a clockwise direction.

00:22Inserting it into hole in spool.

00:25Spool may have to be rotated slightly. So lock can line up with hole spool

00:31lock, disengage, disengage by pulling out and rotating one quarter turn in a counterclockwise

00:37direction. Adjusting tension note, avoid adjusting tension

00:43above or below rated capacity of balancer tightening spring over its rated capacity will

00:49shorten cable stroke and decrease spring life. If spring is loosened to lower than minimum

00:54capacity, the safety device may engage preventing operation to increase

01:00tension. Turn the hex drive in a clockwise direction.

01:04Also, if balancer will not hold tool in raised position, increase tension by turning drive

01:09clockwise to decrease tension, turn hex drive counter clockwise

01:16direction. Also, if tool is difficult to pull down,

01:20decrease tension by turning drive counter clockwise procedure to disengage locking

01:26device in the event that the safety device becomes engaged and locks the spool.

01:32Follow this procedure to disengage the safety device loosen allen screws and

01:39remove all safety stop pins, rotate tension adjustment worm

01:46approximately 100 turns in a counter clockwise direction.

01:49In order to ensure that all tension is relieved from power,

01:52spring rotate, tension adjustment, worm 115 to 120

01:59turns in a clockwise position. To ensure that the safety pin on the spring

02:02spool assembly is retrieved back into the spool.

02:08Hang the tool balancer reel by the upper hook and load the reel with suitable weight within

02:12the rated capacity.

02:14Pull the load up and down to ensure that the safety pins will not lock the spool,

02:20then replace all safety stop pins and tighten Allen's screws,

02:25hang tool from lower hook on wire, rope and adjust tension to desired balance range.

02:32Contact your local distributor if it still doesn't work properly.
