  6. N12 30.5 MM 16 Pushbutton Continuous Hinge Enclosure 13.5X12.5X6 Carbon Steel - Gray

N12 30.5 MM 16 Pushbutton Continuous Hinge Enclosure 13.5X12.5X6 Carbon Steel - Gray

By Wiegmann

Catalog ID: PBYX16

By Wiegmann
Catalog ID:  PBYX16
Prop 65 - Cancer & Reproductive Harm Notice
N12 30.5 MM 16 Pushbutton Continuous Hinge Enclosure 13.5X12.5X6 Carbon Steel - Gray

Designed to hold 30.5 mm oil-tight pushbuttons, switches, and pilot lights with extra size to allow 2.50 in. between centers of pushbutton holes. Provides protection against dirt, dust, oil and water.

  • Fabricated from 14 gauge steel. Continuously welded seams ground smooth. Cover held in place by continuous hinge. Back panel included with enclosure. Closed cell oil resistant neoprene gasket. External mounting plates, top and bottom of enclosure. Captivated cover screws thread into sealed wells. Standard "4-way" pushbutton holes accept all brands of oil-tight push buttons, switches, and pilot lights. Grounding provisions provided.

    • Product Details

    General

    Application Designed to hold 30.5mm oil-tight pushbuttons, switches, and pilot lights with extra size to allow 2.50" between centers of pushbutton holes. Provide protection against dirt, dust, oil, and water.
    Color Ansi-61 Gray Textured
    Construction Continuously Welded Seams
    Cover Type Pushbutton;Screw
    EU RoHS Indicator No
    Finish Type Polyester Powder
    Listings UL, CSA
    Material Carbon Steel
    Mounting Type External Mounting Plates
    Number of Holes 16
    Series PBXY
    Type Wide Center Space Pushbutton Enclosure
    UPC 786725432554

    Dimensions

    Actual Height 13.500 in
    Actual Width 12.500 in
    Depth 6 in
    Height 14 in
    Weight 19 lb
    Width 13 in

    Certifications and Compliance

    Certified Listed cULus
    Nema Rating 12
    UL Listed Yes

    Logistics

    Carton Quantity 1
