389 | Ex e | Breather Drain
Brand:
Hawke
The Hawke 389 metallic breather drain is designed to prevent condensation and drain moisture from hazardous area enclosures. Dual Certified ATEX/IECEx (along with many more) for use in Increased Safety (Exe) and Dust (Ext) protection concepts. Also approved for use in Group I Mining Applications.
- Metallic construction
- Stainless Steel Internal Sinter
- Certified Exe/Ext
- M20 & M25 mounting thread options
- Supplied with metallic castellated locknut for mounting to thin walled enclosures
- Integral Nitrile or SIlicone O-Ring - Maintains IP66
Manufactured in Brass, Nickel Plated Brass, Stainless Steel – Grade 316L. O Ring manufactured from Silicone Rubber.
Product details
General
Application
Hazardous Areas Zone 1, Zone 21, Zone 2, Zone 22 and Mining Applications
Ingress Protection
IP66 to IEC/EN 60529
Material
Manufactured in Brass (Standard), Nickel Plated Brass or 316L Stainless Steel
Operating Temperature
- -60°C to +80°C (with Nitrile O-Ring)
- -60°C to +160°C (with Silicone O-Ring)
Series
Fittings for Hazardous Areas
Certifications And Compliance
Certification
- Ex II 2GD EX eb IIC Gb
- Ex tb IIIC Db
- Ex I M2 Ex eb I Mb
- IEC/EN 60079-0
- IEC/EN 60079-7
- IEC/EN 60079-31
- Baseefa 11ATEX0153X
- BAS21UKEX0043X
- BAS11.0075X
- ABS: 1u-LD1653734-PDA
- BV: 43523/A1
- EAC: No EA3C RU C-GB.HA91.B00265/21
- EQM: 20-11-27224/Q20-11-000979/NB0007
- Inmetro: IEx 15.0292U
- CSA C22.2 No 0-10
- CSA/UL 60079-0
- CSA/UL 60079-7
- CSA/UL 60079-31
- IEC 60529
- NEC: Class 1 Zone 1 AEx eb IIC Gb; Zone 21 Aex tb IIIC Db
- CEC: Ex eb IIC Gb; Ex tb IIIC Db
- cCSAus Listing: 2700364
Hazardous Rating(s)
- Ex II 2GD Ex eb IIC Gb
- Ex tb IIIC Db
- Ex I M2 Ex eb I Mb
- Class 1 Zone 1 AEx eb IIC Gb
- Zone 21 AEx tb IIIC Db
Industry Standard(s)
IEC/EN/CSA/UL 60079-0, 7, 31CSA C22.2 No 0-10
