Acoustic Leak Detection

RF ZoneScan, Acoustic Leak Detection

Brand: Aclara

Acoustic leak detection combined with Aclara's RF Network technology, forming a comprehensive leak detection system

Are you aware that you're losing water – and revenue – due to faulty pipes, but unsure where the leaks are occurring? Aclara's RF ZoneScan Distribution Leak Detection solution is a fixed network, correlated acoustic leak detection system that precisely locates leaks within water distribution systems — to within 1-3 feet. This system actively and accurately locates even the smallest and quietest leaks through daily remote correlation and monitoring, pinpointing the source of water loss. With real-time, daily leak monitoring, utilities can precisely determine the optimal times to schedule maintenance crews, thereby preventing costly service disruptions. As a smart infrastructure solution, Aclara RF ZoneScan leverages the proven infrastructure used by Aclara RF AMI. It can be implemented as a standalone fixed network solution or as a valuable add-on to Aclara RF AMI, pinpointing water loss within a distribution system and delivering clear value and benefits for both utilities and consumers

  • Reclaim lost water revenue
  • Avoid high-cost catastrophic pipe failure
  • Extend the lifecycle costs of infrastructure and treatment plants
  • Conserve water and power
  • Meet consumer and regulatory service expectations

The RF ZoneScan acoustic leak detection system offers a suite of features and benefits designed to enhance water management efficiency and accuracy across utility networks. It features pinpoint accuracy using correlated, time-synchronized sound recordings to precisely identify leak locations, minimizing water loss. Its automated data collection requires minimal operator intervention, streamlining operations and cutting labor costs.

General

Color

black

Compatibility

Single or dual port, standard and extended range MTU with remote antenna connector

Ingress Protection

IP67

Operating Temperature

-40°C to +70 °C

Storage Temperature Range

(-40°C to +85°C)

Dimensions

Depth

1.8 in

Height

5.5 in

Weight

1.5 lb

Width

2.8 in

Electrical Ratings

Frequency Rating

450-470 MHz

Certifications And Compliance

Hazardous Rating(s)

ADA compliant

Industry Standard(s)

  • FCC part 90
  • Industry Canada RSS-119

Operational

Compatibility

Single or dual port, standard and extended range MTU with remote antenna connector

Operating Temperature

-40°C to +70 °C

Storage Temperature Range

(-40°C to +85°C)
