4 in. Square Nonmetallic Cable Box, 2-5/8 in. Deep

By Raco

Catalog ID: 7232RAC

By Raco
Catalog ID:  7232RAC
4 in. Square Nonmetallic Cable Box, 2-5/8 in. Deep
  • RACO® Nonmetallic cable boxes provide the installer with a cost alternative that is lightweight and easy to install
  • Self-clamping wire entry clamps
  • RACO® BOX-LOC® for metal studs can be installed to either 7220RAC or 7232RAC. With just a push, it simply snaps into the grooves on the side of the box. The 978 far-side support can be added to secure installation

Product Details

General

Bracket Type No Bracket
Cable Clamps 10
Color Gray
Type Box
UPC 050169972328
Wiring System Nonmetallic Sheathed Cable

Dimensions

Actual Depth 2.625 in
Cubic Capacity 32.0 cu.in
Depth 2.625 in
Height 5.188 in
Weight 0.4 lb
Width 4 in

Certifications and Compliance

Certified Listed UL Listed
Description SPEC - Certification Canada 1,233,900; 1,237,515.

Logistics

Carton Quantity 8
Pallet Quantity 384
