Trefoil Cable Cleat, Med‑Duty, AL, 1.18–1.38", 30–35 mm
*Representative image
+1
New
Trefoil Cable Cleat, Med‑Duty, AL, 1.18–1.38", 30–35 mm
Brand: Burndy
Catalog ID: ALTMD030035
Medium‑Duty Trefoil Aluminum Cable Cleat, for cable diameters 1.18–1.38", 30–35 mm in trefoil formations
- Designed, tested, and third party certified in accordance with IEC 61914:2021
- 86kA peak short circuit rating
- 5083 Aluminum cleat with LSF base, booster, and liners
- Suitable for use with cable diameters 17 to 150mm / 0.67-5.91 in
- Single M12 (1/2) or Double M10 (3/8) Bolts
General
Catalog Number
ALTMD030035
Duty
Medium
Material
Aluminum
Operating Temperature
-60°C to +60 °C
Product Type
Trefoil
Type
Trefoil
UPC
621945753952
Dimensions
Height
3.7 in
Package Height
0 in
Package Length
0 in
Package Weight
0 lb
Package Width
0 in
Weight
0.5 lb
Width
4.3 in
Electrical Ratings
Duty
Medium
Short Circuit Rating
86 kA
Conductor Related
Cable Entry
Side Opening
Certifications And Compliance
Industry Standard(s)
IEC 61914
Operational
Operating Temperature
-60°C to +60 °C
