Anchor, Tool, Locking Dog Assembly, 15,000 ft-lb rating

By CHANCE Utility

Catalog ID: C3030981

By CHANCE Utility
Catalog ID:  C3030981
15K Locking Dog Assembly.

Ensure your crews are ready to properly and safely install anchors by selecting CHANCE anchors and installation tooling.

  • Locking Dog Assembly bolts to Kelly Bar Adapter and attaches to Anchor Drive Wrench
  • TOUGH ONE locking dog assembly has twelve holes for 5/8" bolts on a 7-5/8" bolt circle and comes with twelve 5/8" Grade 5 bolts, nuts and lock washers.
Contact Us
Add to List

More Options

Get a Quote

Product Details

General

Application Anchor/Pile Installation
Bolt Grade 2
Coating Painted
Number of Bolt Holes 12
Torque Rating 15000 ft-lbs
Type Anchor/Pile Installation Tools
UPC 096359015406

Dimensions

Anchor Installation Hole Size 0.625 in
Diameter - Bolt 0.625 in
Diameter - Bolt Circle 7.625 in
Dimensions 10.500 in x 10.500 in x 9.500 in
Height 9.500 in
Length 10.500 in
Weight 34.300 lb
Width 10.500 in

Logistics

Pallet Quantity 27
Standard Package 1

Resources and Downloads

Specifications

C3030981 Specification Sheet

Catalogs

Anchor Tools (4A_CA06122E))

Literature

Download All
Anchoring (CA12002E)
CHANCE Anchor Installation Tools: Product Feature & Selection Guide (BR06167E)
CHANCE Anchor Tool Inspection and Maintenance (TD06031E)

Installation/Instruction Manual (IOM)

Instructions for CHANCE PISA Locking Dog Assembly

Sales Drawings

Tough One Wrench System (SA30310008)

Videos

CHANCE Tough One and PISA Anchor Installation (VI0645E)

CHANCE Locking Dog Repair Kit (VI0658E)

CHANCE Pisa Drive Tools (VI0633E)
