Stud to Cable(s) or Tube(s)
337 Products
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADSC14912
"Bolted Stud Connectors, Connecting Stud to Flat, Stud Dia./Thd.- 1-1/2”-12, Flat Bar width-4”, Material: Castings- Aluminum Alloy, Stud Mounting Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATL3430G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-1-1/4”-12, Tubing IPS-1-1/4”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADST141412
"Bolted Stud Connectors, Connecting Stud to Cable, Stud Dia./Thd.- 1-1/8”-12,Conductor Range: AAC-600-900 MCM, ACSR- 556.5-795 MCM, Dia.-0.870”-1.108”, Material: Castings- Aluminum Alloy, Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH2420G9012
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-3-1/4”-12, Tubing IPS-3”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATL1120G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-2”-12, Tubing IPS-3”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADST14149012
"Bolted Stud Connectors, Connecting Stud to Cable, Stud Dia./Thd.- 1-1/4”-12,Conductor Range: AAC-900-1250 MCM, ACSR- 715.5-1113 MCM, Dia.- 1.108”-1.293”, Material: Castings- Aluminum Alloy, Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADST16149012
"Tin Plated Bolted Stud Connectors, Connecting Stud to Flat, Stud Dia./Thd.- 2”-14, Flat Bar width-4”, Material: Castings- Aluminum Alloy, Stud Mounting Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATL2420G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-4”-12, Tubing IPS-4”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH2440G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-4”-12, Tubing IPS-4”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH1406G9012
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-2”-12, Tubing IPS-1-1/4”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH3040G12
"Bolted Stud Connectors, Connecting Stud to Two Cables or Tubes, Stud Dia./Thd.- 1-1/8”-12, Copper Conductor Range: Cable - #2 Sol.-1000 MCM, Cable Dia.- 0.258”-1.152”, Tubing IPS - 3/8” - 3/4”, Material: Castings-Bronze Alloy, Hardware-Silicon Bronze or Stainless Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATL2030G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-3-1/2”-12, Tubing IPS-3”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH3224G9012
"Bolted Stud Connectors, Connecting Stud to Two Cables or Tubes, Stud Dia./Thd.- 1-1/2”-12, Copper Conductor Range: Cable - #6 Sol.-500 MCM, Cable Dia.- 0.162”-0.813”, Tubing IPS - 3/8”-1/2”, Material: Castings-Bronze Alloy, Hardware-Silicon Bronze or Stainless Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADSC11712
"Bolted Stud Connectors, Connecting Stud to Cable, Stud Dia./Thd.- 1-3/4”-12,Conductor Range: AAC-900-1250 MCM, ACSR- 715.5-1113 MCM, Dia.- 1.108”-1.293”, Material: Castings- Aluminum Alloy, Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH1212G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-1-3/4”-12, Tubing IPS-1-1/2”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH2424G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-3-1/2”-12, Tubing IPS-3”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADST06069016
"Bolted Stud Connectors, Connecting Stud to Tube, Stud Dia./Thd.- 2”-12, Tubing IPS/EHIPS -2”, Material: Castings- Aluminum Alloy, Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADSC16712
"Bolted Stud Connectors, Connecting Stud to Flat, Stud Dia./Thd.- 1-3/4”-12, Flat Bar width-4”, Material: Castings- Aluminum Alloy, Stud Mounting Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADSC14169012
"Bolted Stud Connectors, Connecting Stud to Flat, Stud Dia./Thd.- 1-1/4”-12, Flat Bar width-3”, Material: Castings- Aluminum Alloy, Stud Mounting Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH1420G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-2”-12, Tubing IPS-3”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADST30249012
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.- 1-1/8”-12, Tubing IPS-1-1/2”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH3020G12
"Bifurcating Stud Connector To Two Flat Pads, EHV(500 kV), Stud Dia. /thd.- 2”- 12, The connectors are designed for use with Type CCL-EHV compression lugs, This connector is designed to clamp terminal pads of a maximum thickness of 1”, Material: Castings - Aluminum Alloy, Stud Clamping Hardware - Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH1614G9012
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-2-1/2”-12, Tubing IPS-2”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADSC141112
"Bolted Stud Connectors, Connecting Stud to Flat, Stud Dia./Thd.- 1-1/8”-12, Flat Bar width-2”, Material: Castings- Aluminum Alloy, Stud Mounting Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADSC141312
"Bolted Stud Connectors, Connecting Stud to Flat, Stud Dia./Thd.- 1-1/8”-12, Flat Bar width-4”, Material: Castings- Aluminum Alloy, Stud Mounting Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATL2024G9012
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-3-1/4”-12, Tubing IPS-3”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: ADSC161312
"Bolted Stud Connectors, Connecting Stud to Flat, Stud Dia./Thd.- 1-1/2”-12, Flat Bar width-4”, Material: Castings- Aluminum Alloy, Stud Mounting Hardware- Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH1214G12
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-1-3/4”-12, Tubing IPS-2”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH3020G9012
"Bifurcating Stud Connector To Two Flat Pads, EHV(500 kV), Stud Dia. /thd.- 2”- 12, The connectors are designed for use with Type CCL-EHV compression lugs, This connector is designed to clamp terminal pads of a maximum thickness of 1”, Material: Castings - Aluminum Alloy, Stud Clamping Hardware - Aluminum Alloy"
Stud Connector, Aluminum
By ANDERSON
Catalog ID: DSATLH1414G9012
"Bolted Expansion Stud Connectors, Connecting Aluminum Tubing to Copper Stud, Stud Dia./Thd.-2”-12, Tubing IPS-2-1/2”, Material: Castings-Aluminum Alloy-Tube Clamping and Guide, Ball Bronze Alloy-Stud Clamping, Preformed Laminated Shunts-Copper (Tinned Contacts), Hardware-Stainless Steel and Galvanized Steel"
